Yeong-Shing Wu1, Chang-You Tsai2, Ken-Hui Chang This email address is being protected from spambots. You need JavaScript enabled to view it.2, Chow-Feng Chiang This email address is being protected from spambots. You need JavaScript enabled to view it.1 1 Department of Public Health, China Medical University, Taichung 40402, Taiwan
2 Department of Safety, Health and Environmental Engineering, National Yunlin University of Science and Technology, Yunlin 64002, Taiwan
Received:
June 29, 2020
Copyright The Author(s). This is an open access article distributed under the terms of the Creative Commons Attribution License (CC BY 4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are cited.
Revised:
October 3, 2020
Accepted:
November 3, 2020
Download Citation:
||https://doi.org/10.4209/aaqr.2020.06.0358
Wu, Y.S., Tsai, C.Y., Chang, K.H., Chiang, C.F. (2021). Impact of Air Pollutants Emitted by Taichung Power Plant on Atmospheric PM2.5 in Central Taiwan. Aerosol Air Qual. Res. 21, 200358. https://doi.org/10.4209/aaqr.2020.06.0358
Cite this article:
The Taichung Power Plant (TCPP) is the second largest thermal power plant in the world and has been a highly controversial source of PM2.5 emissions. In this study, the CMAQ/MM5 model was validated and used to simulate the PM2.5 levels of the 11 stations in central Taiwan. The Base Case with all emission sources and the Control Case without TCPP emission were simulated. The difference between the two simulated results determines the contribution of TCPP emission. The results showed that most of the daily average contribution was less than 5 µg m–3 at each station in year. However, outlier contribution, representing the extreme episode, could reach to 15 µg m–3 in autumn. Although the maximum annual average contribution of TCPP to a single station was 2.0%, the maximum daily and hourly average contribution could be as high as 17% and 60%, respectively. In most stations, the contribution of the red-grade days (> 54 µg m–3) accounted for less than 10% in a year. The contribution might be underestimated as the temporal variation was not considered particularly in the peak-power operation of summer.HIGHLIGHTS
ABSTRACT
Keywords:
PM2.5, CMAQ, Taichung Power Plant, Air pollution
The Taichung Power Plant (TCPP) is located in central Taiwan. It is equipped with 10 coal-fired units and 4 gas turbine units. The total installed capacity is 5.78 GW. It is the largest thermal power plant in Taiwan and the second largest thermal power plant in the world. TCPP provides approximately 19% of the country's electricity (Chen, 2017). Due to the largest power generation and the largest PM2.5 emissions, TCPP has been a highly controversial emission source between the Taiwan’s central government and local governments. The central government claims that if TCPP was closed, it would only improve the air quality of PM2.5 in the central Taiwan by 2–3% on annual average. Overseas sandstorms and local traffic emissions are more important sources of contribution. This statement is supported by many researchers. One of these studies used a Community Multi-scale Air Quality (CMAQ) model to simulate the impact of TCPP on the air quality in Tainan. The results showed that the annual average contribution of PM2.5 was only 2.8%, which was lower than the 3.5% of diesel vehicles in Tainan (Lu et al., 2019). Another study used a hybrid model of CMAQ and AERMOD. The study concluded that a 40% reduction in TCPP power generation could only reduce the PM2.5 concentration by 1.25% based on daily average. On the other hand, reducing traffic flow by 30% could reduce the PM2.5 daily average in Taichung by 6.6% (Lai et al., 2019). However, these studies only explored the impact of TCPP over this dispute in a single city or on a single episode. The International Agency for Research on Cancer (IARC) determines outdoor PM2.5 as Group 1 that is carcinogen to human (IARC, 2013, 2015). Studies have shown that for every 10 µg m–3 increase in the annual average concentration of PM2.5, the mortality of all-cause, cardiopulmonary, and lung cancer will increase by 4%, 6%, and 8%, respectively (Pope et al., 2002, 2009). More notably, many studies have indicated that short-term exposure to PM2.5 increases the risk of hospitalization for cardiovascular and respiratory diseases (Dominici et al., 2006; Wellenius et al., 2012; Shah et al., 2016). Based on epidemiological studies, the American Heart Association (AHA) found that when the daily average of PM2.5 increases by 10 µg m–3, the relative risk of cardiovascular mortality increases by 0.4–1.0% (Brook et al., 2004, 2010). This indicates that the short-term adverse effect of PM2.5 exposure cannot be ignored by the central authority as the mode of public perception is inextricably tiered to local context (Bickerstaff and Walker, 2001; Huang, 2015). The annual average assessment alone was not adequate to clarify this major controversy. The purpose of this study was to evaluate the contribution of TCPP emissions on the increase in the atmospheric PM2.5 in central Taiwan. Firstly, two simulation scenarios of Base Case and Control Case were performed at the study 11 stations in central Taichung. Then, the difference of the two simulated concentrations at each station was determined as the contribution of TCPP. The focus of this study was to evaluate the different contribution of yearly, daily, and hourly averages in a year. Fig. 1 is the map of the study site of TCPP, showing the enlarged 11 stations in central Taiwan. These stations were built and managed by the Taiwan Environmental Protection Agency (TEPA) for the routine monitoring of PM2.5. The nested gridding method is normally used to balance the simulation efficiency and performance (Byun and Ching, 1999; Byun and Schere, 2006). In this study, a nesting ratio of 3 was used with the largest domain of 81 km × 81 km in the first layer covering the most areas of East Asia. The fourth layer of 3 km × 3 km covers the entire Taiwan. The CMAQ system developed by the U.S. Environmental Protection Agency (U.S. EPA, 2018) was used in this study. The system is consisted of: (1) Four-dimensional meteorological data generated by the fifth-generation Penn State / NCAR Mesoscale Model (MM5) and assimilated by the weather data collected in Taiwan; (2) Taiwan emission data of anthropogenic and biological sources from Taiwan Emission Data System (TEDS 9.0) (TEPA, 2016b) and Taiwan Biogenic Emissions Inventory System (TBEIS), respectively (Chang et al., 2009). Table 1 gives the annual emissions of PM2.5, SOx, NOx and VOC of TCPP and all emission sources in Taiwan; (3) Multi-resolution Emission Inventory for Chinese anthropogenic emissions (MEIC) (Li et al., 2014; Zheng et al., 2014; Liu et al., 2015); (4) Anthropogenic emissions of Intercontinental Chemical Transport Experiment-Phase B (INTEX-B) for other areas of East Asia (Zhang et al., 2009); and (5) Biomass emissions of East Asia Biogenic Emissions Inventory System (EABEIS) (Chang et al., 2005). The TEPA’s "Guideline for Simulation of Air Quality Model in Taiwan" (TEPA, 2015), was followed for the performance evaluation of the CMAQ modeling system of this study. The monitored data are required to validate with all the monitored data at all the relevant stations of interest. The mean fractional bias (MFB) and the mean fractional error (MFE) were used as the evaluation indicators as defined below: where, M = the number of all stations, N = the number of simulated days, Pi,k = the predicted value of the k-th station on the i-th day, Oi,k = the monitored value of the k-th station on the i-th day. The acceptable goals were MFB ≤ ±30% and MFE ≤ 50%, while the acceptable criteria were MFB ≤ ±60% and MFE ≤ 75% (Boylan and Russell, 2006). At least 60% of the stations must meet the following criteria: (1) correlation coefficient (R) > 0.55, (2) MFB < ± 35%, (3) MFE < 55%. The Base Case simulation was first performed with all the emissions of Taiwan and the relevant foreign countries. The TCPP-Control Case was then performed by using all the emissions, meteorological, initial and boundary conditions same as in the Basic Case, except for the TCPP emissions. Four seasons of January, April, July, and October in 2013 were simulated, representing winter, spring, summer, and autumn, respectively. The simulated concentration of the Control Case was subtracted from that of the Control Case to obtain the PM2.5 contribution of the TCPP emissions at the 11 stations in central Taiwan. The simulated PM2.5 daily averages of each station were grouped into yellow (< 35µg m–3), orange (35–54 µg m–3), or red (> 54 µg m–3), respectively (TEPA, 2012, 2016a). The yellow grade indicates that the air quality meets the standard, but may have a slight effect on a very small number of extremely sensitive people. The orange grade means that the air quality exceeds the standard, which may affect the health of sensitive people, but the effect on the general public is not obvious. The red grade means that it has an effect on the health of all people, and may have a serious health impact on sensitive people. Fig. 2 is the Base Case simulation result of PM2.5 annual averages of the entire Taiwan. As expected, the high-level contours were found in the western part of the highly industrialized and urbanized area, while low concentrations appeared in eastern part of the underdeveloped area. A hot spot of annual averages (21–42 µg m–3) was found in the southwestern area of Kaohsiung and Pingtung (27–45 µg m–3). The inland areas of Yunlin, Chiayi and Tainan had higher concentrations than their coastal areas. This finding is generally consistent with many previous studies (Lai et al., 2019; Lu et al., 2019). The simulated and monitored PM2.5 daily averages of all the 11 stations were fairly correlated (Fig. 3). As further analyzed in Fig. 4, a few points at Dali, Jhongming, and Situn stations were found to be highly overestimated in January and October. This was probably due to the imperfect wind field simulations associated with the complex terrain of the study area in these seasons. Nevertheless, the validated R = 0.62–0.74, MFB = -1.3–5.3% and MFE = 34–53% (n = 1,342) all meet the performance requirements (R > 0.55, MFB < ± 35%, and MFE < 55%). To analyze the central tendency and the outlier of the simulated daily average of each station, the whisker box plot was used. The inner line of the box is the median. The bottom and top values of the box are P25 and P75, respectively, which are the larger value of {minimum value of all data, P25 – 1.5 × (P75 – P25)}, and the smaller value of {maximum value of all data, P75 + 1.5 × (P75 – P25)}, respectively. The two ends of the whisker drawn in straight are the minimum and the maximum. The solid dot of the whisker is the outlier. As shown in Fig. 5 (a) for Base Case, spring (April) and summer (July) generally had better PM2.5 air quality from the prospective of lower P75 values and much lower extremes. Except for autumn (October), as shown in Fig. 5 (b), the contribution of most TCPP operations was less than 5 µg m–3. The outlier contribution of PM2.5, representing the extreme episode, in autumn was the highest, which could reach to greater than 15 µg m–3. The variation of seasonal outlier contribution could be due to the different prevailing winds in different seasons in the study area. By contract, as shown in Fig. 5 (c), the highest percentage contribution (> 15%) was only occurred in summer (Jul) due primarily to its low base case levels of PM2.5. When the temporal TCPP emission was considered, the percentage contribution could be even higher in the peak-power generation in summer (Farkas et al., 2015, 2016). As further analyzed in Fig. 6, the contribution of the yellow-grade days was quite limited by 1.1%, 2.6%, 1.0%, and 2.6% in winter, spring, summer, and autumn, respectively. The percent contribution of the red grade days was also marginal. Surprisingly, the relative contribution of the red grade days in summer (July) was as high as 33% due to a low Base Case percentage (1.8%) of the red-grade days. In the other three seasons, the relative contribution of the red-grade days was 11%, 8.7%, and 3.1% in spring, autumn, and winter, respectively. It was further found in Table 2 that most stations had a low relative contribution of the yellow grade days (< 3%) and the red-grade days (< 10%) in a year. Erlin station had the highest relative contribution (4.4%) of the yellow grade days in a year. Situn (11%) and Changhua (13%) had a relative contribution of the red grade days of greater than 10%. The highest relative improvement of the red grade days was located at Erlin station (25%) due to a low Base Case percentage (6.6%) of the red grad days in a year. As shown in Table 3, the simulated maximum contribution in a year for each station ranged 1.5–4.3%, 1.9–6.1%, 10–17%, and 38–60% for the yearly, monthly, daily, and hourly average. For better comparison, the annual average contribution of each station was used as the reference to calculate the maximum contribution multiplier (Nx). Their occurrence seasons were also identified. It could be seen when the averaging time period was shortened, the maximum contribution by TCPP operation at each station increased. The annual average contribution of TCPP was as much as 3.0%. But on the basis of the hourly average, the maximum contribution could be as high as 60%. This suggests that, in evaluating the contribution of specific emission sources, use of the annual average or daily average alone (Lai et al., 2019; Lu et al., 2019;) could sometimes be misleading. From the aspect of toxicological effect of PM2.5, short-term exposure cannot be ignored by the quality authority (Bickerstaff and Walker, 2001; Huang, 2015). In addition, the public is more perceived to the hourly average or even the hourly peak measurements and the mode of public perception is inextricably tiered to local context (Bickerstaff and Walker, 2001; Brook et al., 2004; 2010; Huang, 2015). According to the public IoT data service platform (TMOST, 2020), the TEPA currently collects the continuous PM2.5 monitoring of about 3,000 micro-sensors in the entire Taiwan in every 3 minutes. It is speculated that the short-term continuous monitoring data may provoke more public attention, although the reliability of the data is often questioned. Several important conclusions and recommendations obtained in this study were as follows: We declare no conflict of interests. We thank the Taiwan Environmental Protection Agency for releasing various emission and monitoring data used in this study.1 INTRODUCTION
2 METHODS
2.1 The Study SiteFig. 1. Site map of the 4-layer nested simulation domain of the Taichung Power Plant (TCPP) and 11 monitoring stations in central Taiwan.
2.2 The CMAQ Modeling System
2.3 Performance Evaluation
2.4 Contribution of the TCPP
2.5 The Pollution Grades
3 RESULTS AND DISCUSSION
3.1 Performance EvaluationFig. 2. Spatial distribution diagram of the annual PM2.5 concentration simulated in January, April, and October 2013 for the Base Case of this study.
Fig. 3. Performance evaluation of the CMAQ model, showing the linear correlation (R = 0.66) between the simulated vs. monitored daily PM2.5 concentrations at 11 stations in January, April, July and October 2013.
Fig. 4. Comparison of the temporal trend of the simulated (line) and monitored (circle) daily PM2.5 concentrations at Dali, Jhongming and Situn stations in January, July, April, and October 2013.
3.2 Contribution of Daily AverageFig. 5. Simulated PM2.5 daily averages in each season 2013: (a) Concentration of Base Case; (b) Contribution of TCPP; and (c) Percentage contribution of TCPP; showing the median, the bottom, top, P25, P75, minimum and maximum (line) and outlier (dot) values of the Whisker box.
Fig. 6. Percentages of the yellow-grade, orange-grade, and red-grade days in central Taiwan: (a) Normal operation of TCPP of Base Case; (b) Closure of TCPP of Control Case.
3.3 Contribution of Different Averaging Times
4 CONCLUSIONS AND RECOMMENDATIONS
